Rockwell Automation Publication 193-UM015D-EN-P - February 2015 449
Troubleshooting Chapter 11
Power
Under kW 2 1
Over kW 2 2
Under kVAR Consumed 2 3
Over kVAR Consumed 2 4
Under kVAR Generated 2 5
Over kVAR Generated 2 6
Under kVA 2 7
Over kVA 2 8
Under PF Lagging 2 9
Over PF Lagging 2 10
Under PF Leading 2 11
Over PF Leading 2 12
Control
Test 3 1
PTC 3 2
DeviceLogix 3 3
Operator Station 3 4
Remote Trip 3 5
Blocked Start 3 6
Hardware Fault 3 7
Configuration 3 8
Option Match 3 9
Feedback Timeout 3 10
Expansion Bus 3 11
Number Of Starts 3 12
Operating Hours 3 13
Nonvolatile Memory 3 14
Test Mode 3 15
Analog
Analog Module 1 - Input Channel 00 4 1
Analog Module 1 - Input Channel 01 4 2
Analog Module 1 - Input Channel 02 4 3
Analog Module 2 - Input Channel 00 4 4
Analog Module 2 - Input Channel 01 4 5
Analog Module 2 - Input Channel 02 4 6
Analog Module 3 - Input Channel 00 4 7
Analog Module 3 - Input Channel 01 4 8
Analog Module 3 - Input Channel 02 4 9
Analog Module 4 - Input Channel 00 4 10
Analog Module 4 - Input Channel 01 4 11
Analog Module 4 - Input Channel 02 4 12
Code Long Blink Pattern Short Blink Pattern
