Appendix B Parameter List
Voltage Monitor
(Continued)
60 AvgVoltageLtoN Average RMS
Voltage Line-
Neutral
UINT 2 10 0 65535 0 Volt
61 VoltageUnbalance Voltage Unbalance USINT 1 1 0 255 0 %
62 VoltageFrequency Voltage Frequency UINT 2 10 0 2500 0 Hz
63 VPhaseRotation Voltage Phase
Rotation
(ABC or ACB)
UINT 2 1 0= NoRotation
1= ABC
2= ACB
0
Power Monitor 64 L1RealPower Phase L1 Real
Power.
DINT 4 1000 -2000000000 2000000000 0 kW
65 L2RealPower Phase L2 Real
Power.
DINT 4 1000 -2000000000 2000000000 0 kW
66 L3RealPower Phase L3 Real
Power.
DINT 4 1000 -2000000000 2000000000 0 kW
67 TotalRealPower I.TotalRealPower Total Real Power DINT 4 1000 -2000000000 2000000000 0 kW
68 L1ReactivePower Phase L1 Reactive
Power
DINT 4 1000 -2000000000 2000000000 0 kVAR
69 L2ReactivePower Phase L2 Reactive
Power
DINT 4 1000 -2000000000 2000000000 0 kVAR
70 L3ReactivePower Phase L3 Reactive
Power
DINT 4 1000 -2000000000 2000000000 0 kVAR
71 TotalReactivePwr I.TotalReactivePower Total Reactive
Power
DINT 4 1000 -2000000000 2000000000 0 kVAR
72 L1ApparentPower Phase L1 Apparent
Power
DINT 4 1000 0 2000000000 0 kVA
73 L2ApparentPower Phase L2 Apparent
Power
DINT 4 1000 0 2000000000 0 kVA
74 L3ApparentPower Phase L3 Apparent
Power
DINT 4 1000 0 2000000000 0 kVA
75 TotalApparentPwr I.TotalApparentPower Total Apparent
Power
DINT 4 1000 0 2000000000 0 kVA
76 L1PowerFactor Phase L1 True
Power Factor (PF)
INT 2 10 -1000 1000 0 %
77 L2PowerFactor Phase L2 True
Power Factor (PF)
INT 2 10 -1000 1000 0 %
78 L3PowerFactor Phase L3 True
Power Factor (PF)
INT 2 10 -1000 1000 0 %
79 TotalPowerFactor I.PowerFactor Total True Power
Factor (PF)
INT 2 10 -1000 1000 0 %
Energy Monitoring 80 kWhTimes10E9 Total Real Energy
(kWh) Word 10^9
INT 2 1 -999 999 0
81 kWhTimes10E6 Total Real Energy
(kWh) Word 10^6
INT 2 1 -999 999 0
82 kWhTimes10E3 Total Real Energy
(kWh) Word 10^3
INT 2 1 -999 999 0
83 kWhTimes10E0 Total Real Energy
(kWh) Word 10^0
INT 2 1 -999 999 0
84 kWhTimes10E-3 Total Real Energy
(kWh) Word 10^-3
INT 2 1 -999 999 0
85 kVARhCon10E9 Total Reactive
Energy Consumed
(kVARh) Word
10^9
INT 2 1 -999 999 0
86 kVARhCon10E6 Total Reactive
Energy Consumed
(kVARh) Word
10^6
INT 2 1 -999 999 0
87 kVARhCon10E3 Total Reactive
Energy Consumed
(kVARh) Word
10^3
INT 2 1 -999 999 0
88 kVARhCon10E0 Total Reactive
Energy Consumed
(kVARh) Word
10^0
INT 2 1 -999 999 0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
