Rockwell Automation Allen-Bradley E300

480 Rockwell Automation Publication 193-UM015D-EN-P - November 2013
Appendix B Parameter List
Current Setup
continued
277 L1OCTripLevel C.L1OverCurrentTripLimit L1 Over Current
Trip Level
USINT 1 1 10 200 100 %
278 L1OCWarningLevel C.L1OverCurrentWarnLimit L1 Over Current
Warning Level
USINT 1 1 10 200 90 %
279 L2OCTripDelay L2 Over Current
Trip Delay
USINT 1 10 0 250 10
Second
s
280 L2OCTripLevel C.L2OverCurrentTripDelay L2 Over Current
Trip Level
USINT 1 1 10 200 100 %
281 L2OCWarningLevel C.L2OverCurrentTripLimit L2 Over Current
Warning Level
USINT 1 1 10 200 90 %
282 L3OCTripDelay C.L2OverCurrentWarnLimit L3 Over Current
Trip Delay
USINT 1 10 0 250 10
Second
s
283 L3OCTripLevel C.L3OverCurrentTripDelay L3 Over Current
Trip Level
USINT 1 1 10 200 100 %
284 L3OCWarningLevel C.L3OverCurrentTripLimit L3 Over Current
Warning Level
USINT 1 1 10 200 90 %
285 LineLossInhTime C.L3OverCurrentWarnLimit Line Loss Inhibit
Time
USINT 1 1 0 250 10
Second
s
286 L1LossTripDelay C.LineLossInhibitTime L1 Line Loss Trip
Delay
USINT 1 10 0 250 10
Second
s
287 L2LossTripDelay C.L1LineLossTripDelay L2 Line Loss Trip
Delay
USINT 1 10 0 250 10
Second
s
288 L3LossTripDelay C.L2LineLossTripDelay L3 Line Loss Trip
Delay
USINT 1 10 0 250 10
Second
s
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
