Rockwell Automation Allen-Bradley E300

496 Rockwell Automation Publication 193-UM015D-EN-P - November 2013
Appendix B Parameter List
Analog3 Setup
(Continued)
508 InAnMod3Ch01Type C.Analog3.Ch01InputRangeType_0
C.Analog3.Ch01InputRangeType_1
C.Analog3.Ch01InputRangeType_2
C.Analog3.Ch01InputRangeType_3
C.Analog3.Ch01InputRangeType_4
Assignment for
Analog Module 3
Input Channel 01
function
USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm
0
509 InAMod3Ch1Format C.Analog3.Ch01InputFormat_0
C.Analog3.Ch01InputFormat_1
C.Analog3.Ch01InputFormat_2
Assignment for
Analog Module 3
Input Channel 01
Data Format
USINT 1 1 0= EngUnits
1= EngUnitsTimes10
2= RawProportional
3= ScaledForPID
0
510 InAMod3C1TmpUnit C.Analog3.Ch01InputTempMode Assignment for
Analog Module 3
Input Channel 01
Temperature Units
USINT 1 1 0=DegreesC
1=DegreesF
0
511 InAMod3C1FiltFrq C.Analog3.Ch01InputFilter_0
C.Analog3.Ch01InputFilter_1
C.Analog3.Ch01InputFilter_2
Assignment
Analog Module 3
Input Channel 01
Filter Freq
USINT 1 1 0=17Hz
1=4Hz
2=62Hz
3=470Hz
0
512 InAMod3C1OpCktSt C.Analog3.Ch01InputOpenWire_0
C.Analog3.Ch01InputOpenWire_1
Indicates Analog
Module 3 Input
Channel 01 Open
Circuit State
USINT 1 1 0=Upscale
1=Downscale
2=Zero
0
513 InAnMod3Ch1RTDEn C.Analog3.Ch01InputTwoWireRTD Enable Analog
Module 3 Input
Channel 01 to
function with RTD
BOOL 1 1 0=3-wire
1=2-wire
0
514 InAMod3C1TripDly C.Analog3.Ch01InputTripDelay Analog Module 3
Input Channel 01
Trip Delay
USINT 1 10 0 250 10
Second
s
515 InAMod3C1TripLvl C.Analog3.Ch01InputTripLimit Level (in selected
Units) where
Analog Input
generates a trip
UINT 2 1 -32768 32767 0
516 InAMod3C1WarnLvl C.Analog3.Ch01InputWarnLimit Level (in selected
Units) where
Analog Input
generates a
warning
UINT 2 1 -32768 32767 0
517 InAnMod3Ch02Type C.Analog3.Ch02InputRangeType_0
C.Analog3.Ch02InputRangeType_1
C.Analog3.Ch02InputRangeType_2
C.Analog3.Ch02InputRangeType_3
C.Analog3.Ch02InputRangeType_4
Assignment for
Analog Module 3
Input Channel 02
function
USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
6= 100Pt385
7= 200Pt385
8= 500Pt385
9= 1000Pt385
10=100Pt3916
11= 200Pt3916
12= 500Pt3916
13= 1000Pt3916
14= 10Cu426
15= 120Ni618
16= 120Ni672
17= 604NiFe518
18= 150ohm
19= 1000ohm
20 = 3000ohm
21= 6000ohm
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
