Appendix B Parameter List
Analog4 Setup
(continued)
554 InAMod4C2TripDly C.Analog4.Ch02InputTripDelay Analog Module 4
Input Channel 02
Trip Delay
USINT 1 10 0 250 10
Second
s
555 InAMod4C2TripLvl C.Analog4.Ch02InputTripLimit Level (in selected
Units) where
Analog Input
generates a trip
UINT 2 1 -32768 32767 0
556 InAMod4C2WarnLvl C.Analog4.Ch02InputWarnLimit Level (in selected
Units) where
Analog Input
generates a
warning
UINT 2 1 -32768 32767 0
557 OutAnMod4Type C.Analog4.Ch00OutputRangeType_0
C.Analog4.Ch00OutputRangeType_1
C.Analog4.Ch00OutputRangeType_2
C.Analog4.Ch00OutputRangeType_3
Assignment for
Analog Module 4
Output function
USINT 1 1 0= Disabled
1= 4To20mA
2= 0To20mA
3= 0To10Volts
4= 1To5Volts
5= 0To5Volts
0
558 OutAnMod4Select C.Analog4.Ch00OutputMode Assignment of
parameter data
value to drive
Analog Module 4
Output
USINT 1 1 0= AveragePctFLA
1= ScaledAvgPctFLA
2= PercentTCU
3= GFCurrent
4= CurrentUnbalance
5= AvgLLVoltage
6=VoltLLUnbalance
7= TotalkW
8= TotalkVA
9= TotalkVAR
10= TotalPF
11= UserDLXData
0
559 OutAnMod4EFltAct C.Analog4.Ch00OutputFaultMode_0
C.Analog4.Ch00OutputFaultMode_1
Analog Module 4
Output action on
an Expansion Bus
fault
USINT 1 1 0= Zero
1= Maximum
2= Minimum
3= HoldLastState
0
560 OutAnMod4PFltAct C.Analog4.Ch00OutputProtectionFaultMode_0
C.Analog4.Ch00OutputProtectionFaultMode_1
Analog Module 4
Output action on a
protection fault
USINT 1 1 0= Zero
1= Maximum
2= Minimum
3= HoldLastState
0
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
