Rockwell Automation Publication 193-UM015D-EN-P - February 2015 523
EtherNet/IP Information Appendix C
Instance 2 is the Predefined Group 2 Connection Set Polled IO Message
Connection. The following instance 2 attributes are supported:
Table 543 - Connection Object — CLASS CODE 0x0005 Instance 2 Attributes
Attribute ID Access Rule Name Data Type Value
1GetState USINT
0=nonexistant
1=configuring
3=established
4=timed out
2 Get Instance Type USINT 1= I/O Connection
3 Get Transport Class Trigger USINT
0x82 - Server, Transport Class 2
(If alloc_choice != polled and ack
suppression is enabled
then value = 0x80)
4 Get Produced Connection ID UINT
01111xxxxxx
xxxxxx= node address
5 Get Consumed Connection ID UINT
10xxxxxx101
xxxxxx= node address
6 Get Initial Comm Characteristics USINT 0x21
7 Get Produced Connection Size UINT 0 to 8
8 Get Consumed Connection Size UINT 0 to 8
9 Get/Set Expected Packet Rate UINT in milliseconds
12 Get/Set Watchdog Action USINT
0=transition to timed out
1=auto delete
2=auto reset
13 Get Produced Connection Path Length UINT 8
14 Get/Set Produced Connection Path 21 04 00 25 (assy inst) 00 30 03
15 Get Consumed Connection Path Length UINT 8
16 Get/Set Consumed Connection Path 21 04 00 25 (assy inst) 00 30 03
