SATO FX3-LX User Manual

11
Do not set on an
unstable area
• Do not set on an unstable area, such as a wobbly table or slanted
area or an area subject to strong vibration. If the product falls off or
topples over, it could injure someone.
Do not place
containers full of water
or other liquid on the
product
• Do not place flower vases, cups, or other containers holding liquids,
such as water or chemicals, or small metal objects near the product.
If they are spilled and get inside the product, immediately turn off the
power switch, unplug the power cord from the outlet, and contact
your SATO reseller or technical support center. Using the product in
this condition could cause a fire or electric shock.
Do not put objects
inside the product
• Do not insert or drop in metal or burnable objects inside the product’s
openings (cable outlets, etc.). If foreign objects do get inside the
product, immediately turn off the power switch, unplug the power
cord from the outlet, and contact your SATO reseller or technical
support center. Using the product in this condition could cause a fire
or electric shock.
Do not use other than
the specified voltage
• Do not use other than the specified voltage. Doing so could result in
fire or electric shock.

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
