Safety Precautions
16
Replacing the Battery
Pack
Be sure to charge the battery pack before its first use or when it has
not been used for a long time.
When not using the battery pack, store it in a location with low
humidity to avoid the battery from leaking or rusting.
Clean the terminals of the battery pack with a dry cloth before use
since dirty terminals may cause an unstable connection, battery
exhaustion or an inability to charge.
Use only the specified battery pack.
When replacing the battery pack, make sure to install the pack in
the correct orientation. Incorrectly replacing the battery creates
the danger of injury or damage to surrounding areas, or causes
explosion.
Replace with a small-size rechargeable battery (Lithium ion battery).
Apply insulation treatment to the old battery pack by sealing the
contact with tape or the like and ask our sales representative or
service center for the measures to be taken to recycle the reusable
materials. Do not place the battery pack together with other batteries
such as dry batteries.
The life expectancy of the lithium ion battery pack varies depending
on usage. We recommend that you replace the battery after 300
charge cycles or 3 years from the date of first use, whichever comes
first.
If you notice any dents or cracks on your battery crust caused by
strong impacts or shocks, stop using the battery immediately and
replace it with a new one. Continued use under these conditions may
lead to abnormal overheating or fire.
Power cords and
cables
Grab power cords and cables by their plug when removing from
electrical outlets or connector ports.
Removing power cords and cables by grabbing the cord/cable may
result in exposure of wires, breakage, fire, or electric shock.
Do not place power cords and cables near heaters or other sources
of heat. Placing power cords and cables near heaters or other
sources of heat may result in melting of the power cord/cable
sheathing, fire, or electric shock.
Opening and closing
the print head
When opening and closing the print head, be careful not to insert
foreign materials, other than media, in the print head. Otherwise, it
may result in injury or damage.

Table of Contents

Other manuals for SATO FX3-LX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the SATO FX3-LX and is the answer not in the manual?

SATO FX3-LX Specifications

General IconGeneral
CutterYes
CertificationEN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodesAZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID moduleNo
Maximum resolution- DPI
Maximum print height500 mm
Maximum printing width80 mm
Battery voltage14.4 V
AC input voltage100 - 240 V
Battery capacity1950 mAh
AC input frequency50 / 60 Hz
Suitable for use in country/locationEurope
Sustainability certificatesENERGY STAR
DisplayLCD
Control typeTouch
Product colorWhite
Display diagonal7 \
Display resolution480 x 800 pixels
International Protection (IP) codeIPX2
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.1
USB 2.0 ports quantity4
Connectivity technologyWired & Wireless
Media thickness0.14 - 0.19 mm
Maximum roll diameter105 mm
Storage temperature (T-T)-5 - 60 °C
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)30 - 90 %
Operating relative humidity (H-H)30 - 75 %
Cables includedAC
Quantity per pack1 pc(s)
Languages supportMulti
Weight and Dimensions IconWeight and Dimensions
Depth225 mm
Width132 mm
Height180 mm
Weight3000 g
