SATO FX3-LX User Manual

487
Environmental Conditions
Item Description
Operating Temperature
Continuous/Cutter/Tear-off/Partial cutter/Dispenser mode
0 to 35 °C (32 to 95 °F)
Linerless Cutter/Linerless Tearoff mode
5 to 35 °C (41 to 95 °F)
Storage Temperature
(Without Media)
-5 to 60 °C (23 to 140 °F)
Charging Temperature 0 to 35°C (32 to 95 °F)
Operating Humidity 30 to 75% RH (Non-condensing)
Storage Humidity (Without
Media)
30 to 90% RH (Non-condensing)
Print
Item Description
Print Method Direct thermal
Print Speed
With the AC adapter
2 to 6 inches/sec (50.8 to 152.4 mm/sec)
With the optional battery
2 to 4 inches/sec (50.8 to 101.6 mm/sec)
Resolution (Head Density) 305 dpi (12 dots/mm)
Non-printable Area Pitch direction (Excludes liner)
Top
1.5 mm (0.06")
Bottom
1.5 mm (0.06")
Width direction (Excludes liner)
Left
1.5 mm (0.06")
Right
1.5 mm (0.06")
Printable Area Length 500 mm (19.69") x Width 80 mm (3.15")

SATO FX3-LX Specifications

General

Cutter	Yes
Certification	EN55032, EN55024, EN61000-3-2 / 3-3, EN300 330-2 / -1, EN301 489-1 / -3 / -17, FCC Part15 Subpart B, ICES 003 UL60950-1, CSA C22.2 No.60950-1, IEC/EN60950-1 FCC Part15 Subpart C/E, ISED RSS-Gen, ISED RSS-247, EN 300 328, EN 301 893
Built-in barcodes	AZTECCODE, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN13, EAN8, GS1 COMPOSITE, GS1 DataBar, GS1-128, Industrial 2/5, Interleaved 2/5, Matrix 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in RFID module	No
Maximum resolution	- DPI
Maximum print height	500 mm
Maximum printing width	80 mm
Battery voltage	14.4 V
AC input voltage	100 - 240 V
Battery capacity	1950 mAh
AC input frequency	50 / 60 Hz
Suitable for use in country/location	Europe
Sustainability certificates	ENERGY STAR
Display	LCD
Control type	Touch
Product color	White
Display diagonal	7 \
Display resolution	480 x 800 pixels
International Protection (IP) code	IPX2
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.1
USB 2.0 ports quantity	4
Connectivity technology	Wired & Wireless
Media thickness	0.14 - 0.19 mm
Maximum roll diameter	105 mm
Storage temperature (T-T)	-5 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 75 %
Cables included	AC
Quantity per pack	1 pc(s)
Languages support	Multi

Weight and Dimensions

Depth	225 mm
Width	132 mm
Height	180 mm
Weight	3000 g
