Page 115
STAT
IM
2000/2000S Service Guide
96-108639 Rev 3.0
5. STAT
IM
2000S Calibration
STATIM 2000/2000S/2000 G4 Service Guide
7. Turn ON the unit while keeping Unwrapped and Wrapped button pressed to enter STAT
IM
Service Mode.
8. This Service Mode is password protected, enter password to continue (default password is:
Unwrapped, Wrapped, R&P and Stop keys pressed in that order).
Keypad functions (Unit LCD or Control Box) at this time will be:
t Unwrapped Key: Select next item in the menu.
t Wrapped Key: Select previous item in the menu.
t Rubber and Plastics Key: Enter current selection
t Toggle using keypad through the menu selection to reach Calibration option and press
R&P key.
The display should be similar to the diagram below.
Where
t PPP.P = actual chamber pressure in kPa.
t PO = chamber pressure hexadecimal offset value
t TTT.T = theoretical pressure calculated from the actual chamber temperature.
t CO = chamber temperature hexadecimal offset value
t CCC.C = actual chamber temperature in °C
IMPORTANT NOTES:
t Remember – the steam generator thermocouple does NOT require calibration.
t The VREF does not need adjustment.
PPP.P PO TTT.T CO
CCC.C
