Page 53
STAT
IM
2000/2000S Service Guide
96-108639 Rev 3.0
3. Troubleshooting Cycle Faults
STATIM 2000/2000S/2000 G4 Service Guide
8. Upon entering this mode the display will show the following for a short time:
And then, it will display all of the available cycles (7 cycles).
9. Press the “Unwrapped” button and the unit will “lock in” the cycles selected at steps 2, 3 and
4, and “lock out” the unselected cycles. The display will show for a short time:
And then, it will display only the cycles selected (3 cycles + drying) at steps 2, 3 and 4 plus the
drying cycle.
10. Please note that if the “Unwrapped” button is pressed again the cycles will be unlocked and so
on.
11. Turn unit off and remove calibration jumper. The changes will be saved automatically.
12. For unlocking the cycles on a unit with locked cycles, follow steps 6 and 7. Upon entering
locking/unlocking mode the display will show:
And display only the selected cycles.
13. Press the “Unwrapped” button to unlock the cycles.
14. The display will now show the following, for a short time:
And then, it will display all of the available cycles (7 cycles).
15. Turn unit off and remove calibration jumper. The changes will be saved automatically.
Locking procedure for revision 7.x controller boards/software revision R6xx
1. Turn the unit ON.
2. Press “Unwrapped” button repeatedly until the desired cycle is displayed.
3. Press “Wrapped” button repeatedly until the desired cycle is displayed.
4. Press “Rubber and Plastics” button repeatedly until the desired cycle is displayed.
5. Turn the unit OFF.
6. Press and hold the “Unwrapped” and “Wrapped” buttons together and switch the unit ON.
7. You should now have entered the ‘Service Menu’ and you will be asked for a password. The
default unit password is entered by pressing the “Unwrapped”, “Wrapped”, “Rubber and
Plastics” and “Stop” buttons.
8. The display should now show the following:
Cycle UNLOCKED
Available cycles
Cycle UNLOCKED
Available cycles
>Calibration
Time/Date Setup
Cycle LOCKED
Available cycles
Cycle LOCKED
Available cycles
