sennebogen 830 E - Lubricating the Lubrication Points Manually; Checking the Fill Level in the Central Lubrication System

Start-up - Tests before start-up
4 - 11
830 / 07.2012 Original operating instructions
4.6.4 Lubricating the lubrication points manually
Note
More information can be found in Section 3.5.3.
4.6.5 Checking the fill level in the central lubrication system
The central lubrication system automatically lubricates the slewing
track of the swiveling connection as well as the bearings of the
equipment. The lubrication cycle is pre-set at the factory.
Note
The preset lubricating cycle can be shortened. See the documentation
on the central lubrication system in Chapter 10 Appendix of the
operating instructions.
1 Grease reservoir — note MIN/MAX marking
2 Refill with grease **/***
3 Refill with grease */**
4 Adjust the lubrication times
2
1
3
4
