Technical data - Machine
3 - 4
830 / 07.2012
Original operating instructions
3.2 Machine
(*): Note that per 0.5 m mast length, an additional approx. 30 l
(approx. 7.9 gal. (US)) of hydraulic oil is required for special machines
with a mast.
Wheel nuts The tightening torque is 650 Nm. Use a torque wrench.
Fuel tank
- Middle level sensor:
Max. 500 l/max. 132,1 gal. (US)
Approx. 480 l/approx. 126,8 gal.
(US)
Hydraulic tank
- Middle inspection glass:
Max. 310 l/max. 81,9 gal. (US)
Approx. 245 l/approx. 64,7 gal. (US)
Hydraulic system, complete (*)
Approx. 680 l/approx. 179,6 gal. (US)
Axle distributor gearbox Approx. 3.0 l/approx. 0.8 gal. (US)
Differential
Front
Rear
Approx. 11.0 l/approx. 2.9 gal. (US)
Approx. 15.0 l/approx. 4.0 gal. (US)
Hub gears
Front
Rear
Each approx. 2.5 l/approx. 0.7 gal.
(US)
Each approx. 2.5 l/approx. 0.7 gal.
(US)
Swing ring lubrication —
reservoir
Approx.
1.0 l
/approx.
0.26 gal. (US)
Central lubrication system —
reservoir
Approx. 2.5 kg/approx. 5.5 lb
Swing gear Approx. 4.0 l/approx. 1.04 gal. (US)
Tire size Air pressure
bar psi
10.00-20
12.00-20 9 130.53
12.00-24 10 145.04
Tire air pressure
(pneumatic tires)
