Setup work - Mounting/disassembling the counterweight
9 - 5
830 / 07.2012
Original operating instructions
9.3.1 Disassembling the counterweight
DANGER
Angle “a” between the machine and the sling devices must always be 90°.
If the angle is greater or less, the counterweight can tip away from the
machine or injure persons or damage parts of the machine.
Item Description
1 Threaded attachment points for lifting eyes
2 Rear hexagonal screw
3 Lower hexagonal screw
4 Taillight connector
5 Taillight mounting screws
6 Sling devices
7 Counterweight
8 Spacer packs
a Angle for sling devices: 90°
1 Move the upper structure in the direction of travel.
Place the working tools/equipment on the ground.
2 Unscrew the taillight mounting screws (5); withdraw the
taillights slightly. Carefully unplug the connector (4) from each
taillight.
3 Screw the two lifting eyes included with the on-board
accessories completely into the threaded attachment points (1)
for the counterweight.
4 Attach suitable sling devices (6) to the auxiliary crane and the
lifting eyes on the counterweight (7). Keep the sling devices
tensioned.
5 Loosen the hexagonal screw 9. Remove item 10; 11; 12,
loosen the hexagonal screw 13 and unscrew.
6 Loosen and unscrew the lower hexagonal screw (3) from the
counterweight.
