Start-up - Lubricating the machine automatically
4 - 24
830 / 07.2012
Original operating instructions
4.8.3 Adjusting the lubricating cycle
Note
The pre-set lubricating cycle can be shortened. See the documentation
on the central lubrication system in Section 10 of the operating instruc-
tions.
Setting the
parameters (4)
1 Grease reservoir – note MIN/MAX marking
2 Refill with grease **/***
3 Refill with grease */**
4 Adjust the lubrication times
1 Using a flat screwdriver, remove the red frame of the control on
the motor protective housing of the pump and remove the four
Phillips screws as well as the clear cover.
2 Using a Phillips screwdriver, adjust the pause or lubrication
time on both click switches.
3 If the control system is closed improperly, water will infiltrate,
which will void the guarantee.
