sennebogen 830 E - Undercarriage - Crawler

Overview - Undercarriage – crawler
2 - 5
830 / 07.2012
Original operating instructions
2.4 Undercarriage – crawler
*: Optional model/special function
*: Optional model/special function
1 Drive wheel (reverse
direction of travel)
4 Track roller
2 Access ladder 5 Crawler chain
3 Telescoping – attachment
points
6 Idler (forward direction of
travel)
1 Adjustment drive cover 4 Telescoping – arrest
2 Lashing points 5 Lubrication point
3 Lock bolts 6 Slewing ring
1
2* 4
6
3*
5
3*
6
5*
4*
3*
2
1
