sennebogen 830 E - Cooling

SENCON - Sennebogen Control System - Diagnostics
SENCON / 01.2013
5 - 7
5.3.3 Cooling
*Identical: combination cooler for cooling water and hydraulic oil
Hydraulic oil
Cooling water tem
Water cooler* load
Oil cooler* load
Next page
Page back (SCROLL left)
Water cooler fan reversal
Oil cooler fan reversal
Network
Statistics Info/Process data
Parameterization
Error memory
active
active
Cooling water temperature
after cooler
perature Engine
Oil temperature after coole
(SCROLL right)
temperature / Tank
