6.4 Additional displays (optional equipment)
6.4.1 SENNEBOGEN Tool Control
The SENNEBOGEN Tool Control enables operation of several
attachment tools (e.g. grab, demolition hammer) with different
requirements for maximum permissible flow volumes and pressures.
The maximum permissible flow volume and pressure is adapted to the
corresponding work tool by the SENNEBOGEN Tool Control.
CAUTION
Before the work application, select the rating for the respective tool!
Selecting the rating
Note
After releasing the safety lever, the last selected tool is indicated on the
display (3).
12
4
3
1 Start the engine in accordance with Section 4.10.4.
2 Release the safety lever (see Section 6.3.2).
3 Press buttons (1) and (2) and select the desired rating.
The selected tool (rating) appears on the display (3).
