Operation - Operating instruments
6 - 9
830 / 07.2012
Original operating instructions
6.3.2 Safety lever
The safety lever (1) serves as a protective feature.
Safety lever released
(pushed forward)
When the safety lever is released (see illustration)
All hydraulic functions are available.
All work maneuvers can be carried out.
Note
The swing bearing holding brake remains open after the safety lever is
released (pushed forward) if the “right-hand” switch in the right-hand
control panel has previously been actuated.
Loosen the swing bearing holding brake by pressing the “left-hand”
switch in the right-hand control panel (see Section 6.5.6).
Safety lever actuated
(pulled back)
Note
All hydraulic functions are deactivated when the safety lever is
actuated.
