sennebogen 830 E - Operators station;cab with gallery, raising

Operation - Operator's station/cab with gallery, raising
6 - 2
830 / 07.2012
Original operating instructions
6.2 Operator's station/cab with gallery, raising
*: Optional model/special function
Item Description
1 Work lighting
2* Windscreen wiper, roof
3 Windscreen wiper, top
4* Front windshield, top, adjustable
5 Front windshield, bottom
6 Door lock and handle
7* Windscreen wiper, lower
8 24 V plug socket (connection for beacon)
9 Emergency exit — rear window
10 Sliding door
11 Gallery
12 Hammer — emergency exit
1
3
4
5
7*
8*
6
9
10
11
12
2
Emergency exit
