Operation - Operator's station/cab with gallery, raising
6 - 3
830 / 07.2012
Original operating instructions
Note
In an emergency, you can exit via the rear window (9). Use the
emergency hammer (12) to break the window.
Note
The cab door is equipped with an emergency release. If necessary,
consult SENNEBOGEN Customer Service!
Sliding door
The sliding door (1) can be locked in the open position on the side panel
of the cab. You can release the lock again by pulling on the release
lever (2) on the inside of the door.
Front windshield
To open the front windshield, tilt it forward. The top windscreen wiper
swivels ahead with the window. Press on both buttons (4) and swivel
the window ahead. The two shock absorbers hold it in position. Pull the
two grips (3) on the window frame inward to close it. Ensure that the
front windshield latches in place again.
