Operation - Operator's station/cab with gallery, raising
6 - 4
830 / 07.2012
Original operating instructions
Note
Do not switch on the windscreen wiper with the front window open.
Interior lighting The switches (6) enable you to turn the lighting (7,8) on and off.
The spotlight (7) can be adjusted by the operator.
The interior lighting (8) switches on when you open the cab door (9).
The function can be switched off with switch (5).
Washer system The windscreen wipers are operated via the switch on the top right
control panel. The container for cleaning fluid for the washer system is
located behind the left front service access door. Always fill the
container with window antifreeze.
Radio The radio (7) and the loudspeakers (8) are located behind the driver's
seat below the cab roof.
Note
More information can be obtained from the radio manufacturer.
Document case
A SENNEBOGEN document case holding the machine documentation
is located in the cab.
