Technical data - Machine dimensions
3 - 5
830 / 07.2012
Original operating instructions
3.2.1 Crawler
(*): Note that per 0.5 m mast length an additional approx. 30 l
(approx. 7.9 gal. (US)) of hydraulic oil is required for special machines
with pylon.
3.3 Machine dimensions
Note
More information on the dimensions can be found in
S
ECTION 7.2 RAISING THE UPPER STRUCTURE
3.4 Machine weight
Note
More information can be found in S
ECTION 7.1.3 MACHINE WEIGHT.
Subassembly Quantity
Fuel tank
- Middle level sensor:
Max. 500 l/max. 132,1 gal. (US)
Approx. 480 l/approx. 126.8 gal. (US)
Hydraulic tank
- Middle inspection glass:
Max. 310 l/max. 134.7 gal. (US)
Approx. 245 l/approx. 81,9 gal. (US)
Hydraulic system, complete
(*)
Approx. 680 l/approx. 179,6 gal. (US)
Traction gear each approx. 9 l/ approx. 2.4 gal. (US)
Slewing ring lubrication –
reservoir
approx. 1.0 l / approx. 0.26 gal. (US)
Central lubrication system –
reservoir
approx. 2.5 kg / approx. 5.5 lbs
Swing gear approx. 4.0 l / approx. 1.04 gal. (US)
