Start-up - Checking the swing gear fill level
4 - 15
830 / 07.2012 Original operating instructions
Note
Observe the notes in the maintenance instructions and in the
lubrication table.
1 Swing gear
2 Fill level at 15°C–20°C oil temperature (approx. quarter full marking
on the oil expansion tank)
3 Oil expansion tank for each swing gear
4 Allow the oil in the swing gear to cool.
5 Check the oil level:
– Fill level at 15°C–20°C oil temperature (approx. quarter
full marking on the oil expansion tank).
– The oil level can vary according to the oil temperature; up
to a three-quarter filling is possible.
6 If necessary add oil of the specified grade.
