SENCON - Sennebogen Control System - Diagnostics
SENCON / 01.2013
5 - 14
5.3.7 Network
Note
The scroll wheel is used to select the individual components of the
network. Selected components have a green background. Pressing the
scroll wheel takes the operator to the detailed view.
Network
Statistics
Info/Process data
Parameterization
Error memory
Representation of all
network components
Network error/no
connection to network
components
