SENCON - Sennebogen Control System - Settings/Parameterization
SENCON / 01.2013
5 - 24
Note
Calibration is only necessary when a component, a control unit, or the
display has been changed, and after a software or parameter update
has been performed.
Note
If the operator presses the SCROLL button, he enters selection mode
in the list and can change between the sensors.
The selected field has a dark green background. Switch between the
various fields using the SCROLL wheel. If the SCROLL wheel is
pressed again, the detailed view is opened.
Detailed view
WARNING
When calibrating joystick steering and grab turning, the operator must
ensure that the rocker is in the middle position (inoperative position) at
the start. Otherwise, serious problems with the steering could occur as
a result.
After calibration a function test must be performed in a safe area.
First reach minimum value,
then reach maximum value
Save using the SET button
Use the ESC button to reset
value/return to previous view
