Operation - Operating instruments
6 - 12
830 / 07.2012
Original operating instructions
6.3.4 Control lever, right
*: Optional model/special function
**: Optional model, only for joystick steering (mobile)
***: Optional model, only with drive pedal
Pos. Description
1** Steer left (proportional)
2** Steer right (proportional)
3* Magnet unit on
4* Magnet unit off
5*** Drive forward preselection on/off
6*** Drive reverse preselection on/off
