Overview - Upper structure
2 - 8 Original operating instructions 830 / 07.2012
View from above
1
2
3
4
5
6 7
Item Description
1 Hydraulic oil tank
2 Swing gear
3 Exhaust system/exhaust gas treatment
4 Rotor (with slip ring assembly*)
5 SENNEBOGEN Hydroclean
6 Swing gear expansion tank
7 Battery
*Optional
