70 mm = le
g detection/arm detection
•
150 mm = body detection
•
200 mm = body detection
b
Choose the object resolution.
✓
Objects the same size as or larger than the chosen object resolution are reliably
detected.
NOTE
T
he configurable object resolution has an influence on the protective field range availa‐
ble. The finer the object resolution configured for the safety laser scanner, the shorter
the available protective field range.
The protective field range is shown to you, see "Parameters for the safety laser scan‐
ner", page 114.
Multiple sampling
DANGER
H
azard due to lack of effectiveness of the protective device
Persons or parts of the body to be protected may not be recognized or not recognized in
time in case of non-observance.
A higher multiple sampling increases the response time.
b
Make a note of the new response time of the safety laser scanner in Safety
Designer.
b
Adjust the minimum distance from the hazardous point to the new response time.
Multiple sampling indicates how often an object has to be scanned before the safety
laser scanner responds. A higher multiple sampling reduces the possibility that insects,
weld sparks or other particles cause the machine to be shut down. You will increase the
machine’s availability.
A multiple sampling of 2 is the minimum setting.
b
Increase the multiple sampling up to 16.
✓
An object must be this many times.
Table 13: Recommended multiple sampling
Application Recommended multiple sampling
Stationary application: such as horizontal haz‐
ar
dous area protection or vertical hazardous
point protection under clean ambient condi‐
tions
2×
Stationary application: such as vertical access
protection
Only 2-time multiple sampling may be used for
vertical access protection.
2×
Mobile application 4×
Stationary application: such as horizontal haz‐
ar
dous area protection under dusty ambient
conditions
8×
CONFIGURATION 7
8025424/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Pro I/O
113
Subject to change without notice

SICK microScan3 Pro I/O Specifications

General

Scanning angle	275°
Number of fields	128
Dimensions	102 mm x 152 mm x 106 mm
Number of safety outputs	2
Number of OSSD outputs	2
Scanning range	5.5 m
Protective field range	5.5 m
Resolution	30 mm
Number of monitoring cases	128
Response time	60 ms
Interfaces	Ethernet, USB
Operating temperature	+50 °C
Protection class	IP65
Supply voltage	24 V DC
Storage temperature	+70°C
Operating voltage	24 V DC (16.8 V DC ... 28.8 V DC)
Housing material	Plastic
Connection type	Male connector
