microScan3 Pro I/O
Sinusoidal vibrations
50 m/s², 0.35 mm, 10 Hz … 150 Hz
5 m/s², 1.5 mm, 5 Hz … 200 Hz
10 m/s², 3.5 mm, 5 Hz … 150 Hz
Noise vibrations
0.5 m²/s³, 5 Hz … 200 Hz
0.1 m²/s³, 200 Hz … 500 Hz
Shock resistance
4)
Standards
IE
C 60068-2-27
IEC 60721-3-5
IEC TR 60721-4-3
IEC 61496-1
IEC 61496-3
Class
5M1 (IEC 60721-3-5)
3M4 (IEC TR 60721-4-3)
Single shock 50 m/s², 11 ms
Continuous shock
100 m/s², 16 ms
150 m/s², 6 ms
EMC In accordance with IEC 61496-1, IEC 61000-6-2, and
IE
C 61000-6-4
1)
The specified enclosure rating is only valid if the safety laser scanner is closed, the system plug is
mounted, and all of the M12 plug connectors of the safety laser scanner have been closed using a cable
plug connector or using a protective cap.
2)
For ambient light sources directly in the scan plane in accordance with IEC 61496-3: ≤ 3 klx.
3)
IEC 61496-1, no. 4.3.1 and no. 5.4.2, IEC 61496-3, no. 4.3.1 and no. 5.4.2. Condensation has an
inf
luence on normal operation.
4)
For direct mounting.
Miscellaneous data
T
able 37: Miscellaneous data
microScan3 Pro I/O
Wavelength 845 nm
Detectable remission 1.8% … several 1,000%
Maximum uniform contami‐
na
tion of the optics cover
without reducing the detec‐
tion capability
1)
30%
Area where detection capabil‐
it
y is restricted
≤ 50 mm
2)
Light spot size
3)
Devices with a max. protective field range of 4.0 m
At front screen 18 mm × 4 mm
At 4.0 m distance 5 mm × 11 mm
At 5.5 m distance 2 mm × 18 mm
At 9.0 m distance 11 mm × 27 mm
Devices with max. protective field range 5.5 m
At front screen 18 mm × 4 mm
At 4.0 m distance 5 mm × 11 mm
At 5.5 m distance 2 mm × 18 mm
At 9.0 m distance 11 mm × 27 mm
Devices with max. protective field range 9.0 m
TECHNICAL DATA 13
8025424/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Pro I/O
185
Subject to change without notice
