Siemens SIMOCODE pro System Manual

Motor control
SIMOCODE pro
4-14 GWA 4NEB 631 6050-22 DS 03
Extent and application
Depending on the device series, the system provides the following control
functions:
SIMOCODE
Control function pro C (BU1) pro V (BU2)
Overload relay ✓ ✓
Direct starter ✓ ✓
Reversing starter ✓ ✓
Circuit breaker ✓ ✓
Star-delta starter — ✓
Star-delta reversing starter — ✓
Dahlander — ✓
Dahlander reversing Starter — ✓
Pole-changing starter — ✓
Pole-changing reversing starter — ✓
Solenoid valve — ✓
Positioner 1 to Positioner 5 — ✓
Soft starter — ✓
Soft starter with reversing contactor — ✓
Table 4-4: Control functions

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
