Motor control
SIMOCODE pro
4-18 GWA 4NEB 631 6050-22 DS 03
Interlocking time SIMOCODE pro prevents, e.g. in the case of reversing starters,
both contactors from switching on at the same time. Switching
from one direction of rotation to the other can be delayed via the
interlocking time.
Default: 0 s
.
Change-over pause In the "Dahlander" and "Pole-changing starter" control functions,
switching from FAST to SLOW can be delayed by the time
configured.
In the "Star-delta starter" control function, the change-over pause
time extends the time between switching off the star contactor and
switching on the delta contactor by the time configured.
Default: 0.00 s
.
Max. star time For the "Star-delta starter" or the "Star-delta reversing starter"
control function:
Time-dependent switching from star to delta.
Max. star time: 0 - 255 s (default: 20 s
)
Current measuring
module installed
For the "Star-delta starter" or the "Star-delta reversing starter"
control function:
The set current and the switching levels for star-delta switching
depend on the mounting place of the current measuring module.
•Delta
: Set current I
s
is reduced to In x 1/
• In supply cable: Set current
Parameter Description
Table 4-5: General settings and definitions (Cont.)
