Siemens SIMOCODE pro System Manual

Monitoring functions
SIMOCODE pro
GWA 4NEB 631 6050- 22 DS 03
5-9
Trip level, warning level
You can parameterize two different response levels (trip level/warning level).
If the voltage of one or more phases falls below the response level or
warning level, voltage monitoring responds.
Trip level and warning level activity
Here you can specify in which motor operating states the trip level/warning
level is to take effect:
1) When using basic unit 2 (from version *E03*) with a current/voltage
measuring module
Response at trip level
Here you can set how SIMOCODE pro should respond if the trip level is
undershot:
See also "Tables of responses of SIMOCODE pro" in Chapter "Important
information".
Table 5-7: "Trip level" response for voltage monitoring
Trip level: 0 - 2040 V in 8 V increments
Warning level: 0 - 2040 V in 8 V increments
•Always (on)
1)
Trip level/warning level always takes effect,
regardless of whether the motor is running or at
a standstill
• Always, except TPF (on+) Trip level/warning level always takes effect,
regardless of whether the motor is running or at
a standstill.
Exception: "TPF", i.e. motor feeder is in test
position
• If motor is running, except TPF (run) Trip level/warning level only takes effect if the
motor is ON and not in the test position
Response Trip level
Deactivated X
Signaling X
Warning -
Tripping X
Delay 0 - 25.5 s (0.5 s
)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
