Siemens SIMOCODE pro System Manual

Outputs
SIMOCODE pro
6-8 GWA 4NEB 631 6050-22 DS 03
Application examples
• Display of operating states:
You can define which LEDs are to be used for displaying the operating states
(Fault, ON, OFF, Fast, Slow...).
For this, connect the desired LED to the respective "QL." lamp control of the
control function.
In many cases, the LEDs are connected to the QL outputs.
By referring to
Table 4-21 on page 4-65 you can determine which QL outputs are required
for which control functions.
• Transfer of any other information, status information, warnings, faults, etc. to
the yellow LEDs.
Settings
*) No function when using the operator panel with display
Defaults depend on the selected application (template): See Chapter E
"Example circuits".
OP LED Description
Green 1 to Green 4 Control of the "OP LED" function block
with any signal
(any sockets ,
e.g. feedback concerning the "Motor" operating state)
Yellow 1 to Yellow 3* Control of the "OP LED" function block
with any signal
(any sockets
e.g. displays for status, events, faults)
Table 6-3: Operator panel LED settings

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
