Inputs
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
7-11
Application examples
Digital modules allow the number of binary inputs and binary outputs on
basic unit 2 to be increased in increments.
SIMOCODE pro V can thus be extended to a maximum of twelve binary
inputs and seven binary outputs. If assigned accordingly, the input signals
can be also used to activate, for example, function blocks such as "Reset" or
"External Fault". An external fault can be, for example, the binary signal of an
external speed monitor, signaling that the nominal speed of a motor has
been undershot.
Supplying the inputs
See Chapter 1.7.7 "Expansion modules for the SIMOCODE pro V device
series".
Settings
Notice
The delay times of the digital module inputs can only be set and/or are only
relevant when "monostable" or "bistable" is set for digital module 1. The
delay time can not be set if digital module 1 is a DM-F PROFIsafe. If digital
module 1 is a DM-F Local, the delay times can be set using the DIP
switches on the front of the DM-F Local.
Non-safety functions (failsafe digital modules)
• If digital module 1 is a DM-F Local, the DM-F Local is a digital module
with non-safety inputs, relay outputs and diagnostics in a SIMOCODE pro
system.
• If digital module 1 is a DM-F PROFIsafe, the DM-F PROFIsafe is a digital
module with non-safety inputs, relay outputs and diagnostics in a
SIMOCODE pro system.
Detailed information on failsafe digital modules:
See Chapter 1.7.7 "Expansion modules for the SIMOCODE pro V device
series".
Basic unit Description
Delay time
inputs
If required, you can set a delay time for the inputs.
Range: 6, 16, 26, 36 ms
These values are valid for digital modules with a 24 V DC input
supply.
For digital modules with a 110 to 240 V AC/DC input supply, the
values are approx. 40 ms higher.
Table 7-5: "DM1/DM2 inputs" settings
