Siemens SIMOCODE pro System Manual

3UF50 compatibility mode
SIMOCODE pro
9-4 GWA 4NEB 631 6050-22 DS 03
Diagram of diagnostics data
The following table shows the diagnostics data in the 3UF50-compatibility
mode:
Byte
Bit
Setup 3UF50 - device-specific
diagnostics acc. to DP
standard SIMOCODE-DP
Byte
Bit
Setup 3UF50 - device-specific
diagnostics acc. to
SIMOCODE-DP DPV1 standard
Equivalent in SIMOCODE pro V
60x0B
Same as 3UF50 diagnostics
70x81
80x04
60x0E 90x00
7.0 Free 10.0 Free
7.1 Event: DP block 10.1 Event: DP block
Event - Start-up parameter
block active
7.2 Event: Emergency start 10.2 Event: Emergency start
Status - Emergency start executed
7.3 Event: HW test OK 10.3 Event: HW test OK • No fault - HW fault basic unit
• No fault - Module fault
• No fault - Temporary components
7.4 Free 10.4 Free -
7.5 Event: Ext. event 1 10.5 Event: Ext. event 1 Event - Ext. fault 5
7.6 Event: Ext. event 2 10.6 Event: Ext. event 2
Event - Ext. fault 6
7.7 Event: Ext. event 3 10.7 Event: Ext. event 3 -
8.0 Warning: Ext. Warning 11.0 Warning: Ext. warning Warning - Ext. fault 3
8.1 Warning: Unbalance > 40% 11.1 Warning: Unbalance > 40%
Warning - Unbalance
8.2 Event: Failure PLC-CPU 11.2 Event: Failure PLC-CPU Status - PLC/PCS (inverted)
8.3 Warning: Sensor short circuit 11.3 Warning: Sensor short circuit Warning - Thermistor short circuit
8.4 Event: Cooling down period
active
11.4 Event: Cooling down period
active
Status - Cooling down period active
8.5 Status: TPF 11.5 Status: TPF
Status - Test position (TPF)
8.6 Free 11.6 Free
-
8.7 Free 11.7 Free
-
9.0 Warning: Earth fault 12.0 Warning: Earth fault • Warning - Int. earth fault
or
• Warning - Ext. earth fault
9.1 Warning: Overload 12.1 Warning: Overload
Warning - Overload
9.2 Warning: Overload + unbalance 12.2 Warning: Overload + unbalance
Warning - Overload + phase failure
9.3 Warning: I1 response level
overshot
12.3 Warning: I1 response level
overshot
Warning - Warning level I>
9.4 Warning: I1 response level
undershot
12.4 Warning: I1 response level
undershot
Warning - Warning level I<
9.5 Warning: I2 response level
overshot
12.5 Warning: I2 response level
overshot
-
9.6 Warning: I2 response level
undershot
12.6 Warning: I2 response level
undershot
-
Table 9-3: Diagram of the diagnostics data in the 3UF50 compatibility mode
