Siemens SIMOCODE pro System Manual

3UF50 compatibility mode
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
9-5
9.7 Warning: Thermistor 12.7 Warning: Thermistor • Warning - Thermistor overload
• Warning - Thermistor open circuit
• Warning - TM warning T>
• Warning - TM sensor fault
• Warning - TM out of range
10.0 Trip: Earth fault 13.0 Trip: Earth fault
• Trip - Int. earth fault
or
• Trip - Ext. earth fault
10.1 Trip: Overload 13.1 Trip: Overload
Trip - Overload
10.2 Trip: Overload + unbalance 13.2 Trip: Overload + unbalance
Trip - Overload + phase failure
10.3 Trip: I1 response level overshot 13.3 Trip: I1 response level overshot Trip - Trip level I>
10.4 Trip: I1 response level undershot 13.4 Trip: I1 response level undershot Trip - Trip level I<
10.5 Trip: I2 response level overshot 13.5 Trip: I2 response level overshot
-
10.6 Trip: I2 response level undershot 13.6 Trip: I2 response level undershot -
10.7 Trip: Thermistor 13.7 Trip: Thermistor • Trip - Thermistor overload
• Trip - Thermistor short circuit
• Trip - Thermistor open circuit
• Trip - TM trip T>
• Trip - TM sensor fault
• Trip - TM out of range
11.0 Trip: FB ON 14.0 Trip: FB ON
Trip - Feedback ON
11.1 Trip: FB OFF 14.1 Trip: FB OFF
Trip - Feedback OFF
11.2 Trip: Motor blocked 14.2 Trip: Motor blocked Trip - Stalled rotor
11.3 Trip: Positioner blocked 14.3 Trip: Positioner blocked Trip - Stalled positioner
11.4 Trip: Double 0 14.4 Trip: Double 0
Trip - Double 0
11.5 Trip: Double 1 14.5 Trip: Double 1 Trip - Double 1
11.6 Trip: End position 14.6 Trip: End position Trip - End position
11.7 Trip: Antivalence 14.7 Trip: Antivalence
Trip - Antivalence
12.0 Trip: ESB 15.0 Trip: ESB Trip - Ext. fault 4
12.1 Trip: OPO 15.1 Trip: OPO Trip - Operational protection OFF (OPO)
12.2 Trip: UVO 15.2 Trip: OPO
Trip - Undervoltage (UVO)
12.3 Trip: Ext. fault 1 15.3 Trip: Ext. fault 1
Trip - Ext. fault 1
12.4 Trip: Ext. fault 2 15.4 Trip: Ext. fault 2
Trip - Ext. fault 2
12.5 Trip: TPF fault 15.5 Trip: TPF fault
Trip - Cold starting (TPF) fault
12.6 Trip: Runtime ON 15.6 Trip: Runtime ON Trip - Execution ON command
12.7 Trip: Runtime OFF 15.7 Trip: Runtime OFF Trip - Execution STOP command
13.0 Trip: Parameter fault 0 16.0 Trip: Parameter fault 0
Trip - Parameterization
13.1 Trip: Parameter fault 1 16.1 Trip: Parameter fault 1 -
13.2 Trip: Parameter fault 2 16.2 Trip: Parameter fault 2 -
13.3 Trip: Parameter fault 3 16.3 Trip: Parameter fault 3 -
13.4 Trip: Parameter fault 4 16.4 Trip: Parameter fault 4 Trip - Configuration fault
13.5 Trip: Parameter fault 5 16.5 Trip: Parameter fault 5 -
13.6 Trip: Parameter fault 6 16.6 Trip: Parameter fault 6
-
13.7 Trip: Parameter fault 7 16.7 Trip: Parameter fault 7
Trip - HW fault basic unit
Byte
Bit
Setup 3UF50 - device-specific
diagnostics acc. to DP
standard SIMOCODE-DP
Byte
Bit
Setup 3UF50 - device-specific
diagnostics acc. to
SIMOCODE-DP DPV1 standard
Equivalent in SIMOCODE pro V
Table 9-3: Diagram of the diagnostics data in the 3UF50 compatibility mode (Cont.)
