Siemens SIMOCODE pro System Manual

Alarms, faults and system events
SIMOCODE pro
15-2 GWA 4NEB 631 6050-22 DS 03
Event
(alphabetical)
Description Troubleshooting Acknowledg
ement/fault
rectification
Contactor
control
Error
no.*)
Analog module
open circuit
The analog value measuring
circuit is open.
Check the transducer
and the measuring
circuit.
Reset 64
Antivalence Only for positioner 5 control
function: The change-over
contacts of the limit switch do
not issue an antivalent signal.
Limit switch defect, limit
switch open circuit
Tripped
Configuration
fault
The configured device
configuration does not match
the existing configuration.
• Please check whether
all configured
components are
present.
• Check the actual
configuration using
"Configuration".
Rectify the
fault; reset
Tripped 3
DM-F feedback
circuit
DM-F Local or
DM-F PROFIsafe has detected a
fault in the feedback circuit
(when the enabling circuit is
being switched on, the feedback
circuit must be closed.);
The "GF" (Gen. Fault) LED on the
front of the DM-F Local or DM-
F PROFIsafe flashes red
• Check the wiring of
the feedback circuit
• Check the contact
blocks in the feedback
circuit.
Rectify fault
so that the
feedback
circuit is
closed.
Tripped
DM-F safety-
oriented tripping
The DM-F has tripped the
enabling circuit for safety
reasons.
The motor can only be
switched on again after
the DM-F module
enabling circuits have
been closed.
Acknowledg
e with
"Reset", if
auto-reset is
not active.
Tripped
DM-F - Test
requirement
The DM-F Local or DM-F
PROFIsafe
enabling circuits have not been
opened and closed again within
the configured time period.
The function of the
enabling circuit relay
contacts can only be
tested when they are
switched.
Carry out a function test.
Please adopt
the
measures
intended for
this case.
DM-F wiring DM-F module wiring fault (short-
circuit to ground in the sensor
circuit/feedback circuit);
The "GF" (Gen. Fault) LED on the
front of the DM-F Local is lit red.
• Check the wiring of
the sensor circuit/
feedback circuit
• Rectify the fault.
Reset Tripped
DM-FL -
Configuration
deviation
The effective configuration of
the DM-F Local does not
correspond to the parameterized
set configuration.
Check whether the
effective configuration of
the DM-F Local
co
rrespo
nds to the
parameterized set
configuration. Correct
the effective
configuration by
changing the DIP switch
settings or adjusting the
set configuration by
means of
parameterization if
required.
Table 15-1: Alarms, faults and system events

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
