Siemens SIMOCODE pro System Manual

Alarms, faults and system events
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
15-3
DM-FL -
Configuration
mode
The DM-F Local is in
"Configuration mode";
The "DEVICE" LED on the front
of the DM-F Local is lit yellow.
Complete the
configuration (see
system manual "Failsafe
Digital Module
SIMOCODE
pro Safety", Chapter 7.4)
DM-FL - Cross
circuit
DM-F Local sensor circuit cross
circuit.
The "GF" (Gen. Fault) LED on the
front of the DM-F Local is lit red.
• Check the wiring of
both sensor circuits for
cross circuiting
• Rectify the fault.
Reset Tripped
DM-FL -
Simultaneity
The DM-F Local has detected a
discrepancy fault in the two-
channel sensor circuit.
Please check the contact
blocks in the sensor
circuit.
Rectify the
fault by
opening or
closing the
sensor
inputs
Tripped
DM-FL waiting
for start-up test
The DM-F Local is in the
"Waiting for start-up test" state.
Carry out the start-up
test by actuating the
sensor in the sensor
circuit.
DM-FP F PRM
error
The specified PROFIsafe profile
parameters are erroneous or the
specified
PROFIsafe address does not
correspond to the configuration.
Please check the
PROFIBUS/PROFIsafe
parameters of
SIMOCODE pro, which
were set on the DP
Master system.
Double 0 Both torque switches have
activated simultaneously. The
motor feeder has been turned
off.
• Open circuit torque
switch.
• Torque switch is
defective.
Tripped 13
Double 1 Both limit switches have
activated simultaneously.
Limit switch is defective. Tripped 14
End position Except positioner 5 control
function: The state of the limit
switch has changed without a
command (positioner has left
the end position without a
command)
"OPEN/
CLOSED"
counter
command.
Tripped 15
Execution
ON command
The motor feeder could not be
turned on after an ON command
is issued.
• Main circuit is
interrupted (fuse,
circuit breaker)
• The motor contactor or
contactor control is
defective
• Parameter execution
time is too short.
Reset or
OFF
command/
counter-
command
Tripped
Event
(alphabetical)
Description Troubleshooting Acknowledg
ement/fault
rectification
Contactor
control
Error
no.*)
Table 15-1: Alarms, faults and system events (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
