Siemens SIMOCODE pro System Manual

Alarms, faults and system events
SIMOCODE pro
15-4 GWA 4NEB 631 6050-22 DS 03
Execution
STOP command
The motor feeder could not be
turned off after a STOP
command was issued.
• The contactor contact
is welded
• Parameter execution
time is too short
• The "open" end
position has not been
reached during the
parameterized runtime
(only for the
"Positioner" and
"Solenoid valve" control
functions).
Rectify the
fault;
reset
Tripped 9
External earth
fault
External earth-fault monitoring
has activated. An impermissibly
high fault current is flowing.
Please check the motor
connection cable for
damage.
Reset Tripped 29
External fault
1, 2, 3, 4, 5 or 6
A signal is pending at the input
(socket) of the "External fault 1,
2, 3, 4, 5 or 6" standard function.
Check the motor feeder. Tripped 56, 57,
58,
59,
60, 61
Feedback (FB)
OFF
The current flow in the motor
feeder has been interrupted
without the motor feeder being
turned off.
• The main circuit has
been interrupted (fuse,
circuit breaker, main
switch).
• The motor contactor or
contactor control is
defective
Reset or
OFF
command
Tripped 11
Feedback (FB)
ON
Current is flowing in the motor
feeder without the motor feeder
being switched on
• Contactor contacts
have been manually
activated
• Contactor has not
been switched on via
SIMOCODE
Rectify the
fault;
Reset or
OFF
command
Tripped 10
Hardware fault The SIMOCODE pro basic unit
hardware is defective.
Please replace the basic
unit.
See Chapter 13
"Mounting, wiring,
interfaces".
Rectify the
fault
Tripped 0
Internal earth
fault
Internal earth-fault monitoring
response. An impermissibly high
fault current is flowing.
Please check the motor
connection cable for
damage.
Reset Tripped 28
Just one start
possible
The start after the next one
should not be carried out until
the interlocking time has
expired.
Module fault At least one SIMOCODE pro
module is not ready for use.
• The connecting cable
is defective or has not
been plugged in
correctly.
• Module is defective.
Please replace the
module.
For this, see
Chapter 13 "Mounting,
wiring, interfaces".
Rectify the
fault; reset
Tripped 1
Event
(alphabetical)
Description Troubleshooting Acknowledg
ement/fault
rectification
Contactor
control
Error
no.*)
Table 15-1: Alarms, faults and system events (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
