Alarms, faults and system events
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
15-7
Required
function is not
supported
At least one parameterized
function is not supported by the
version of the basic unit.
Activate only the
functions that are
supported by the version
of the basic unit.
For example,
SIMOCODE pro V basic
units with the version
*E01* do not support
voltage measurement,
the temperature module
or the analog module.
Stalled
positioner
The torque switch has activated
before or without the respective
limit switch.
• The positioner may be
blocked.
• Acknowledge the fault
by releasing with the
"OPEN/CLOSED"
counter command.
• Please check the
positioner application
and the limit switches
"OPEN/
CLOSED"
counter
command.
Tripped 12
Stalled rotor The maximum motor current has
exceeded the threshold for
stalled rotor protection.
Possible cause: The motor is
blocked.
Please check the
application that is being
driven by the motor.
Reset Tripped 48
Start-up
parameter block
active
The start-up parameter block
prevents adoption of
SIMOCODE pro parameters that
can be saved in the DP Master.
The block must be set when:
• SIMOCODE ES
or
•SIMATICPDM
is used for parameterizing.
The block may not be set if:
• SIMOCODE pro C/V is
integrated in STEP7 via the
SIMOCODE pro object
manager (OM)
or
• SIMOCODE pro C has been
parameterized via GSD.
Status - Cooling
down period
active
The motor feeder has been
switched off due to overload.
The motor can only be
switched on again after
the cooling down period
has expired.
Event
(alphabetical)
Description Troubleshooting Acknowledg
ement/fault
rectification
Contactor
control
Error
no.*)
Table 15-1: Alarms, faults and system events (Cont.)
Notice
The parameter block is not active
in the case of devices that are st
set to the factory settings or
devices that have been reset to
the factory settings!
