Tables
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
A-15
5.4 Trip - Number of starts > BU1 BU2
5.5 Reserved
6.0 Trips -
Miscellaneous
Trip - Ext. fault 1 BU1 BU2
6.1 Trip - Ext. fault 2 BU1 BU2
6.2 Trip - Ext. fault 3 BU1 BU2
6.3 Trip - Ext. fault 4 BU1 BU2
6.4 Trip - Ext. fault 5 BU2
6.5 Trip - Ext. fault 6 BU2
6.6 Reserved
6.7 Reserved
7.0 Trip - Analog module open circuit AM
7.1 Trip - Test trip BU1 BU2
7.2 DM-F safety-oriented tripping DM-FL DM-FP
7.3 Trip - DM-F wiring DM-FL DM-FP
7.4 Trip - DM-F cross circuit DM-FL
8.0 Warnings - Protection Warning - Overload operation IM UM
8.1 Warning - Unbalance IM UM
8.2 Warning - Overload IM UM
8.3 Warning - Overload + phase failure IM UM
8.4 Warning - Internal earth fault IM UM
8.5 Warning - External earth fault EM
8.6 Reserved
8.7 Warning - Thermistor overload Th
9.0 Warning - Thermistor short circuit Th
9.1 Warning - Thermistor open circuit Th
9.2 Warning - TM warning T> TM
9.3 Reserved
9.4 Warning - M sensor fault TM
9.5 Warning - TM out of range TM
9.6 Reserved
10.0 Warnings -
Level monitoring
Warning - Warning I> IM UM
10.1 Warning - Warning I< IM UM
10.2 Warning - Warning P> UM
10.3 Warning - Warning P< UM
10.4 Warning - Warning cos phi < UM
10.5 Warning - Warning U< UM
10.6 Warning - Warning 0/4-20 mA> AM
10.7 Warning - Warning 0/4-20 mA< AM
11.0 Warning - Stalled rotor IM UM
11.1 Reserved
11.3 Warning - No start possible BU1 BU2
11.4 Warning - Number of motor starts> BU1 BU2
11.5 Warning - Just one start possible BU1 BU2
11.6 Warning - Motor operating hours > BU1 BU2
Byte.Bit Status information Information
Table A-5: Detailed messages of the slave diagnostics (Cont.)
