Data formats and data records
SIMOCODE pro
B-22 GWA 4NEB 631 6050-22 DS 03
12.0 Bit parameters (16)
12.0 No configuration fault due to
OP
Bit 0, 1 0 BU1 BU2
12.1 Start-up parameter block
active
Bit 0, 1 1 BU1 BU2
12.2 Test/Reset buttons blocked Bit 0, 1 0 BU1 BU2
12.3 Bus and PLC/PCS - Reset Bit 0, 1 0 0 = Manual, 1 = Auto BU1 BU2
12.4 Reserved Bit 0
12.5 Reserved Bit 0
12.6 Reserved Bit 0
12.7 Reserved Bit 0
13.0 Diagnostics for process events Bit 0, 1 0 BU1 BU2
13.1 Diagnostics for process
warnings
Bit 0, 1 1 BU1 BU2
13.2 Diagnostics for process faults Bit 0, 1 1 BU1 BU2
13.3 Diagnostics for device faults Bit 0, 1 1 BU1 BU2
13.4 Reserved Bit 0
13.5 Reserved Bit 0
13.6 Bus monitoring Bit 0, 1 1 BU1 BU2
13.7 PLC/PCS monitoring Bit 0, 1 1 BU1 BU2
14.0 Overload protection - Type of
load
Bit 0, 1 0 0 = 3-phase, 1 = 1-phase IM UM
14.1 Overload protection - Reset Bit 0, 1 0 0 = Manual, 1 = Automatic IM UM
14.2 Reserved Bit 0
14.3 Saving change-over command Bit 0, 1 0
14.4 Non-maintained command
mode
Bit 0, 1 0
14.5 Cold starting level (TPF) Bit 0, 1 0 0 = NO contact, 1 = NC contact BU1 BU2
14.6 Load type Bit 0, 1 0 0 = Motor, 1 = Resistive load BU1 BU2
14.7 Reserved Bit 0
15.0 External fault 1 - Type Bit 0, 1 0 0 = NO contact, 1 = NC contact BU1 BU2
15.1 External fault 2 - Type Bit 0, 1 0 BU1 BU2
15.2 External fault 3 - Type Bit 0, 1 0 BU1 BU2
15.3 External fault 4 - Type Bit 0, 1 0 BU1 BU2
15.4 External fault 1 - Activity Bit 0, 1 0 0 = Always, 1 = Only motor ON BU1 BU2
15.5 External fault 2 - Activity Bit 0, 1 0 BU1 BU2
15.6 External fault 3 - Activity Bit 0, 1 0 BU1 BU2
15.7 External fault 4 - Activity Bit 0, 1 0 BU1 BU2
Byte
Bit
Designation
(PRM group)
Type Range De-
fault
Note Informa-
tion
Table B-12: Data record 130 - Basic device parameters 1 (Cont.)
