Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-23
16.0 Bit[2] - Parameters (20)
16.0 Thermistor -
Overload response
Bit[2] 1, 2, 3 3
0 = Deactivated
1 = Signaling
2 = Warning
3 = Tripping
Th
16.2 Thermistor - Response
to sensor error
Bit[2] 0, 1, 2, 3 2 Th
16.4 Internal earth fault - Response Bit[2] 0, 1, 2, 3 0
16.6 Motor protection -
Overload response
Bit[2] 0, 1, 2, 3 3
17.0 Motor protection - Overload
response
Bit[2] 0, 1, 2 2
17.2 Motor protection - Unbalance
response
Bit[2] 0, 1, 2, 3 2
17.4 Trip response I> Bit[2] 0, 1, 3 0
17.6 Warning response I> Bit[2] 0, 1, 2 0
18.0 Trip response I< Bit[2] 0, 1, 3 0
18.2 Warning response I< Bit[2] 0, 1, 2 0
18.4 Stalled rotor - Response Bit[2] 0, 1, 2, 3 0
18.6 Reserved Bit[2] 0
19.0 Monitoring the number of
starts - Response at overshoot
Bit[2] 0, 1, 2, 3 0 BU1 BU2
19.2 Monitoring the number of
starts - Response at pre-
warning
Bit[2] 0, 1, 2 0 BU1 BU2
19.4 Motor operating hours
monitoring - Response
Bit[2] 0, 1, 2 0 BU1 BU2
19.6 Motor stop time monitoring -
Response
Bit[2] 0, 1, 2 0 BU1 BU2
20.0 Ext. fault 1 - Response Bit[2] 1, 2, 3 1 BU1 BU2
20.2 Ext. fault 2 - Response Bit[2] 1, 2, 3 1 BU1 BU2
20.4 Ext. fault 3 - Response Bit[2] 1, 2, 3 1 BU1 BU2
20.6 Ext. fault 4 - Response Bit[2] 1, 2, 3 1 BU1 BU2
21.0 Reserved Bit[2] 0
21.2 Basic unit - Delay inputs Bit[2] 0 - 3 1 Offset 6 ms BU1 BU2
21.4 Timer 1 - Type Bit[2] 0, 1, 2, 3 0 0 = With closing delay
1 = Closing delay with memory
2 = With opening delay
3 = With fleeting closing
BU1 BU2
21.6 Timer 2 - Type Bit[2] 0, 1, 2, 3 0 BU1 BU2
22.0 Signal conditioner 1 - Type Bit[2] 0, 1, 2, 3 0 0 = Non-inverting
1 = Inverting
2 = Edge rising with memory
3 = Edge falling with memory
BU1 BU2
22.2 Signal conditioner 2 - Type Bit[2] 0, 1, 2, 3 0 BU1 BU2
22.4 Non-volatile
element 1 - Type
Bit[2] 0, 1, 2, 3 0 BU1 BU2
22.6 Non-volatile
element 2 - Type
Bit[2] 0, 1, 2, 3 0 BU1 BU2
23.0 Reserved Bit[2] 0 BU1 BU2
23.2 Reserved Bit[2] 0 BU1 BU2
23.4 Reserved Bit[2] 0 BU1 BU2
Byte
Bit
Designation
(PRM group)
Type Range De-
fault
Note Informa-
tion
Table B-12: Data record 130 - Basic device parameters 1 (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
