Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
B-24 GWA 4NEB 631 6050-22 DS 03
23.6 Reserved Bit[2] 0 BU1 BU2
24.0 Bit[4] - Parameters (24)
24.0 External fault 1 -
Reset also by
Bit[4] 0 - 1111B 0101B Bit[0] = Panel reset
Bit[1] = Auto-reset
Bit[2] = Remote reset
Bit[3] = OFF command reset
BU1 BU2
24.4 External fault 2 -
Reset also by
Bit[4] 0 - 1111B 0101B BU1 BU2
25.0 External fault 3 -
Reset also by
Bit[4] 0 - 1111B 0101B BU1 BU2
25.4 External fault 4 -
Reset also by
Bit[4] 0 - 1111B 0101B BU1 BU2
26.0 Limit monitor - Hysteresis for
limit monitors
Bit[4] 0 .. 15 5 BU1 BU2
26.4 Reserved Bit[4] 0
27.0 Reserved Bit[4] 0
27.4 Reserved Bit[4] 0
28.0 Byte parameters (28)
28.0 Internal earth fault - Delay Byte 0 .. 255 5 IM/UM
29.0 Overload protection - Class Byte 5, 10 .. 35,
40
10 BU1
BU2
30.0 Motor protection - Delay
with overload operation
Byte 0 .. 255 5 IM/UM
31.0 Motor protection - Unbalance
level
Byte 0 .. 100 40 IM/UM
32.0 Unbalance protection - Delay
with unbalance
Byte 0 .. 255 5 IM/UM
33.0 Interlocking time Byte 0 .. 255 0
34.0 FB time Byte 0 .. 255 5 0 = Deactivated
35.0 Trip level I> Byte 0 .. 255 0 IM/UM
36.0 Warning level I> Byte 0 .. 255 0 IM/UM
37.0 Trip level I< Byte 0 .. 255 0 IM/UM
38.0 Warning level I< Byte 0 .. 255 0 IM/UM
39.0 Stalled rotor level Byte 0 .. 255 0 IM/UM
40.0 Trip delay I> Byte 0 .. 255 5 IM/UM
41.0 Warning delay I> Byte 0 .. 255 5 IM/UM
42.0 Trip delay I< Byte 0 .. 255 5 IM/UM
43.0 Warning delay I< Byte 0 .. 255 5 IM/UM
44.0 Blocking delay Byte 0 .. 255 5 IM/UM
45.0 Monitoring the number of
starts - Permissible starts
Byte 1 .. 255 1 BU1
BU2
46.0 Reserved Byte 0
47.0 Reserved Byte 0
48.0 Truth table 1 type 3I/1O Byte
0 .. 11111111B 0BU1 BU2
49.0 Truth table 2 type 3I/1O Byte 0 .. 11111111B 0BU1 BU2
50.0 Truth table 3 type 3I/1O Byte
0 .. 11111111B 0BU1 BU2
51.0 Reserved Byte 0
Byte
Bit
Designation
(PRM group)
Type Range De-
fault
Note Informa-
tion
Table B-12: Data record 130 - Basic device parameters 1 (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
