Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
B-28 GWA 4NEB 631 6050-22 DS 03
54.0 Control station - Local control [LC] ON < Byte 0 .. 255 0 Dependen
t on the
control
function
55.0 Control station - Local control [LC] OFF Byte 0 .. 255 0
56.0 Control station - Local control [LC] ON > Byte 0 .. 255 0
57.0 Control station - PLC/PCS [DP] ON < Byte 0 .. 255 56 Default: Cyclic
receive - Bit 0.0
58.0 Control station - PLC/PCS [DP] OFF Byte 0 .. 255 57 Default: Cyclic
receive - Bit 0.1
59.0 Control station - PLC/PCS [DP] ON > Byte 0 .. 255 58 Default: Cyclic
receive - Bit 0.2
60.0 Control Station - PC[DPV1] ON < Byte 0 .. 255 0
61.0 Control Station - PC[DPV1] OFF Byte 0 .. 255 0
62.0 Control station - PC[DPV1] ON > Byte 0 .. 255 0
63.0 Control station - Operator panel [OP] ON < Byte 0 .. 255 0
64.0 Control station - Operator panel [OP] OFF Byte 0 .. 255 0
65.0 Control station - Operator panel [OP] ON > Byte 0 .. 255 0
66.0 Control function - ON < Byte 0 .. 255 73 Default: General
control station
ON <
67.0 Control function - OFF Byte 0 .. 255 74 Default: General
control station OFF
68.0 Control function - ON > Byte 0 .. 255 75 Default: General
control station
ON >
69.0 Control function - Feedback ON Byte 0 .. 255 101 Default: Status -
Motor current
flowing
70.0 External fault 1 - Input Byte 0 .. 255 0 BU1 BU2
71.0 External fault 2 - Input Byte 0 .. 255 0 BU1 BU2
72.0 External fault 3 - Input Byte 0 .. 255 0 BU1 BU2
73.0 External fault 4 - Input Byte 0 .. 255 0 BU1 BU2
74.0 External fault 1 - Reset Byte 0 .. 255 0 BU1 BU2
75.0 External fault 2 - Reset Byte 0 .. 255 0 BU1 BU2
76.0 External fault 3 - Reset Byte 0 .. 255 0 BU1 BU2
77.0 External fault 4 - Reset Byte 0 .. 255 0 BU1 BU2
78.0 Cold starting (TPF) Byte 0 .. 255 0 BU1 BU2
79.0 Test 1 - Input Byte 0 .. 255 59 Default: Cyclic
receive - Bit 0.3
BU1 BU2
80.0 Test 2 - Input Byte 0 .. 255 0 BU1 BU2
81.0 Reset 1 - Input Byte 0 .. 255 62 Default: Cyclic
receive - Bit 0.6
BU1 BU2
82.0 Reset 2 - Input Byte 0 .. 255 0 BU1 BU2
83.0 Reset 3 - Input Byte 0 .. 255 0 BU1 BU2
84.0 Reserved Byte 0
85.0 Reserved Byte 0
86.0 Reserved Byte 0
Byte.
Bit
Designation
(PRM group)
Type Range De-
fault
Note Informa-
tion
Table B-13: Data record 131 - Basic device parameters 2 (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
