Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-29
87.0 Reserved Byte 0
88.0 Truth table 1 3I/1O - Input 1 Byte 0 .. 255 0 BU1 BU2
89.0 Truth table 1 3I/1O - Input 2 Byte 0 .. 255 0 BU1 BU2
90.0 Truth table 1 3I/1O - Input 3 Byte 0 .. 255 0 BU1 BU2
91.0 Truth table 2 3I/1O - Input 1 Byte 0 .. 255 0 BU1 BU2
92.0 Truth table 2 3I/1O - Input 2 Byte 0 .. 255 0 BU1 BU2
93.0 Truth table 2 3I/1O - Input 3 Byte 0 .. 255 0 BU1 BU2
94.0 Truth table 3 3I/1O - Input 1 Byte 0 .. 255 0 BU1 BU2
95.0 Truth table 3 3I/1O - Input 2 Byte 0 .. 255 0 BU1 BU2
96.0 Truth table 3 3I/1O - Input 3 Byte 0 .. 255 0 BU1 BU2
97.0 Reserved Byte 0
98.0 Timer 1 - Input Byte 0 .. 255 0 BU1 BU2
99.0 Timer 1 - Reset Byte 0 .. 255 0 BU1 BU2
100.0 Timer 2 - Input Byte 0 .. 255 0 BU1 BU2
101.0 Timer 2 - Reset Byte 0 .. 255 0 BU1 BU2
102.0 Counter 1 - Input + Byte 0 .. 255 0 BU1 BU2
103.0 Counter 1 - Input - Byte 0 .. 255 0 BU1 BU2
104.0 Counter 1 - Reset Byte 0 .. 255 0 BU1 BU2
105.0 Counter 2 - Input + Byte 0 .. 255 0 BU1 BU2
106.0 Counter 2 - Input - Byte 0 .. 255 0 BU1 BU2
107.0 Counter 2 - Reset Byte 0 .. 255 0 BU1 BU2
108.0 Signal conditioner 1 - Input Byte 0 .. 255 0 BU1 BU2
109.0 Signal conditioner 1 - Reset Byte 0 .. 255 0 BU1 BU2
110.0 Signal conditioner 2 - Input Byte 0 .. 255 0 BU1 BU2
111.0 Signal conditioner 2 - Reset Byte 0 .. 255 0 BU1 BU2
112.0 Non-volatile element 1 - Input Byte 0 .. 255 0 BU1 BU2
113.0 Non-volatile element 1 - Reset Byte 0 .. 255 0 BU1 BU2
114.0 Non-volatile element 2 - Input Byte 0 .. 255 0 BU1 BU2
115.0 Non-volatile element 2 - Reset Byte 0 .. 255 0 BU1 BU2
116.0 Flashing 1 - Input Byte 0 .. 255 0 BU1 BU2
117.0 Flashing 2 - Input Byte 0 .. 255 0 BU1 BU2
118.0 Flashing 3 - Input Byte 0 .. 255 0 BU1 BU2
119.0 Flickering 1 - Input Byte 0 .. 255 0 BU1 BU2
120.0 Flickering 2 - Input Byte 0 .. 255 0 BU1 BU2
121.0 Flickering 3 - Input Byte 0 .. 255 0 BU1 BU2
122.0 Analog parameters (44)
122.0 PLC/PCS analog input Byte 0 .. 255 16 Default: Max.
current I_max
BU1 BU2
123.0 Reserved Byte 0
Byte.
Bit
Designation
(PRM group)
Type Range De-
fault
Note Informa-
tion
Table B-13: Data record 131 - Basic device parameters 2 (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
