Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-35
37.0 EM - Delay Byte 0 .. 255 100 ms 5 EM
38.0 Trip level cos phi< Byte 0 .. 100 1 % 0 UM
39.0 Warning level cos phi< Byte 0 .. 100 1 % 0 UM
40.0 Trip level U< Byte 0 .. 255 8 V 0 UM
41.0 Warning level U< Byte 0 .. 255 8 V 0 UM
42.0 Trip level 0/4-20 mA> Byte 0 .. 255 *128 0 AM
43.0 Warning level 0/4-20 mA> Byte 0 .. 255 *128 0 AM
44.0 Trip level 0/4-20 mA< Byte 0 .. 255 *128 0 AM
45.0 Warning level 0/4-20 mA< Byte 0 .. 255 *128 0 AM
46.0 Trip delay P> Byte 0 .. 255 100 ms 5 UM
47.0 Warning delay P> Byte 0 .. 255 100 ms 5 UM
48.0 Trip delay P< Byte 0 .. 255 100 ms 5 UM
49.0 Warning delay P< Byte 0 .. 255 100 ms 5 UM
50.0 Trip delay cos phi< Byte 0 .. 255 100 ms 5 UM
51.0 Warning delay cos phi< Byte 0 .. 255 100 ms 5 UM
52.0 Trip delay U< Byte 0 .. 255 100 ms 5 UM
53.0 Warning delay U< Byte 0 .. 255 100 ms 5 UM
54.0
Trip delay 0/4-20 mA> Byte 0 .. 255 100 ms 5 AM
55.0
Warning delay 0/4-20 mA> Byte 0 .. 255 100 ms 5 AM
56.0 Trip delay 0/4-20 mA< Byte 0 .. 255 100 ms 5 AM
57.0 Warning delay 0/4-20 mA< Byte 0 .. 255 100 ms 5 AM
58.0 Delay limit 1 Byte 0 .. 255 100 ms 5 BU2
59.0 Delay limit 2 Byte 0 .. 255 100 ms 5 BU2
60.0 Delay limit 3 Byte 0 .. 255 100 ms 5 BU2
61.0 Delay limit 4 Byte 0 .. 255 100 ms 5 BU2
62.0 TM - Hysteresis Byte 0 .. 255 1 K 5 TM
63.0 Max. star time Byte 0 .. 255 1 s 20 Star-delta
starter
64.0 UVO time Byte 0 .. 255 100 ms 0 BU2
65.0 Staggering time Byte 0 .. 255 1 s 0 BU2
66.0 Analog value recording -
Sampling rate
Byte 0 .. 20 5 % 0 BU2
67.0 Calculation module 2 -
Denominator 1
Byte 0 .. 255 0 BU2
68.0 Calculation module 2 - Counter 2 Byte 0 .. 255 0 BU2
69.0 Calculation module 1 -
Denominator
Byte 0 .. 255 0 BU2
70.0 Truth table 4 type 3I/1O Byte 0 .. 11111111B 0 BU2
71.0 Truth table 5 type 3I/1O Byte 0 .. 11111111B 0 BU2
72.0 Truth table 6 type 3I/1O Byte 0 .. 11111111B 0 BU2
73.0 Calculation module 2 - Counter 1 Byte -128 .. 127 0 BU2
74.0 Calculation module 2 -
Denominator 2
Byte -128 .. 127 0 BU2
75.0 DM-F - Test requirement level Byte 0 .. 255 1 week 0 BU2
Byte.
Bit
Designation
(PRM group)
Type Range Unit De-
fault
Note Informa-
tion
Table B-14: Data record 132 - Extended device parameters 1 (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
