1 Main display (OPD)
For details see "Read and adapt main display".
Fig. 1-18: Main display (OPD)
IL1, IL2, IL3 [A]
I_max [A]
IL1, IL2, IL3 [%]
I_max [%]
I_max, Cos
I_max, UL1-N, Cos, S
I_max, UL1-L2, Cos, S
I_max, UL1-N, Cos, P
I_max, UL1-L2, Cos, P
In 1[mA] / Out [mA]
In 2[mA] / Out [mA]
In 1[mA] / In 2 [mA]
Max. temp.
°C
Temperatures °C
UL1-N, UL2-N, UL3-N
Max. temp.
°F
Temperatures °F
UL1-L2, UL2-L3, UL3-L1
I_max, UL1-N, Cos
I_max, UL1-L2, Cos
I_max, UL1-N,
°C
I_max, UL1-L2, °C
Calculator 1
Calculator 2
Energy consumed [kWh]
I_max, UL1-N, °F
I_max, UL1-L2, °F
(OPD above *E04*)
(OPD above *E04*)
(OPD above *E04*)
(OPD above *E04*)
(OPD above *E04*)
