Menu of the operator panel with display
Navigating the menu of the operator panel with display
Main menu (OPD)
For details see "Displays of the operator panel with display"
Fig. 1-17: Main menu (OPD)
Main display
Measured values display
Status display
Statistics/maintenance
Communication (PROFIBUS)
Device I/Os
Display settings
Commands
Status information
Warnings
Faults
Error buffer
Event memory
Identification
Motor protection/motor control
About SIMOCODE
1
3
2
4
5
7
6
8
9
11
10
12
13
14
(OPD above *E04* and BU2 above *E07*)
